Description

ABB 3BHL000385P0101 (5SHX0845F0001) is the core integrated gate-turn-off thyristor (IGCT) power module of ABB's medium-voltage drive system. It is specifically designed for high-voltage and high-power conversion scenarios, and is responsible for the main circuit power switching and energy conversion functions.

This module combines the high withstand voltage advantage of thyristors and the fast turn-off speed of transistors, featuring low on-state loss and high switching speed. It is suitable for harsh conditions such as metallurgy, power, and energy, and provides efficient and stable power core support for medium-voltage frequency converters, reactive power compensation devices, and other applications.

Features

• Model: 3BHL000385P0101 (5SHX0845F0001), Type: IGCT Power Module
• Compatible systems: ABB Medium Voltage AC Frequency Converter (ACS Series), High Voltage High Power Converter Equipment
• Core functions: High Voltage High Current Power Switch, Energy Conversion and Frequency Control
• Performance advantages: Low On-State Voltage Drop, Low Power Consumption Loss, High Switching Frequency, High Conversion Efficiency
• Reliable design: Industrial-grade packaging, excellent heat dissipation performance, suitable for harsh industrial environments
• Integrated features: Built-in Gate Drive and Protection, simplifies system design, easy installation

Technical Specifications
