Description

The XM-361 Universal Temperature module and the XM-362 Isolated Thermocouple Temperature module are members of the Allen-Bradley™ XM® Series, a family of DIN rail mounted condition monitoring and protection modules that operate both in stand-alone applications or integrate with Programmable Logic Controllers (PLCs) and control system networks.

The XM-361 and XM-362 modules are intelligent 6-channel temperature monitors. The XM-361 module can be configured to measure either Resistance Temperature Detector (RTD) or Thermocouple (TC), or a mixture of RTD or TC inputs. The XM-362 module provides 250V dc of channel-to-channel isolation and is specifically designed to measure temperature with Thermocouple inputs.

For applications where it is not possible to integrate XM data directly via DeviceNet, the XM-361 and XM-362 provide separate 4-20mA outputs for each channel. And for applications requiring relays, the modules support connecting up to two XM-441 Expansion Relay modules, providing a total of eight relays. The XM-361/362 can also collect trend data on an event such as a relay actuation.

The modules can operate stand-alone, or they can be deployed on a standard or dedicated DeviceNet network where they can provide real-time data and status information to other XM modules, PLCs, distributed control systems (DCS), and Condition Monitoring Systems.

The XM-361 and XM-362 can be configured remotely via the DeviceNet network, or locally using a serial connection to a PC or laptop. Refer to Chapter 3 for a list of the configuration parameters.
